TP-LINK (InSight S655I) IR Fisheye Network Camera, 360° Coverage, Multiple Display Modes and ePTZ, Smart Detection, IP67, Two-Way Audio

Description

Description

Specification

• #Hide#Series: TP-LINK VIGI
• #Hide#Form Factor: Fisheye
• Suitable for Outdoor: Yes
• Wired/Wireless: Wired
• Interface(s): “1 x RJ45 10/100M Self-Adaptive Ethernet Port, PoE
  DC Power Port
  Built-In Memory Card Slot, Support MicroSD Card, up to 512GB”
• Image Sensor: 1/2.7″” Progressive Scan CMOS
• Resolution: “Main Stream:
  2560×1920, 2256×1696, 2048×1536, 1280×960

  Sub-Stream:
  640×480, 320×240
  “

• Frame Rate: “Main Stream:
  50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
  60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

  Sub-Stream:
  50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
  60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

  Note:
  If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
  If WDR is on, the frame rate only supports up to 15fps.”

• Video Compression: Main Stream: H.265+/H.265/H.264+/H.264
  Sub-Stream: H.265/H.264
• Lens: Type: Fixed Focal Lens

  Focal Length: 1.44 mm

  Aperture: F2.0

  Lens Mount: M12*P0.5

  DORI Distance:
  Detect: 28.8 m (94 ft)
  Observe:12 m (39 ft)
  Recognize: 5.7 m (19 ft)
  Identify: 2.8 m (9 ft)

• Viewing Angle: Horizontal FOV: 180°
  Vertical FOV: 180°
  Diagonal FOV:180°
• Pan/Tilt/Rotation: –
• Day/Night Mechanism: IR Cut Filter
  Day/Night Switch: Unified/ Scheduled/ Auto

  IR LED:
  Quantity: 4
  Range: 10 m
  Wavelength: 850 nm

• Minimum Illumination: “Colour: 0.01 Lux; 0 Lux with IR light”
• Image Settings: “Brightness
  Contrast
  Saturation
  Sharpness
  Exposure
  WDR,
  White Balance
  Prevent Overexposure to Infrared Light
  HLC Adjustable by Client Software”
• Audio Features: Audio Communication: Two-Way Audio
  Audio Input: Yes
  Audio Output: Yes
  Audio Compression: Yes
  Audio Sampling Rate: 8KHz
  Environment Noise Filtering: Yes
  Audio Bit Rate: 64 Kbps (G.711 alaw)
• Alarm & Event Management: “Smart Event Detection:
  Intrusion, Line-Crossing, Region Entering, Region Exiting, Abnormal Sound

  Basic Event:
  Motion Detection, Video Tampering Detection, Exception (Illegal Login)

  Alarm Linkage:
  Memory Card Video Recording, Message Push, Audible Warning, Email Alarm, Upload Capture to FTP”

• Network: “Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP

  ONVIF: Yes

  API: Open Network Video Interface (Profile S/T/G)

  Simultaneous Live View: 3 Main Streams & 3 Sub-Streams

  Client: Utility, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS

  Cloud: Yes”

• Wireless Features: –
• Security: “Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication”
• Management: VIGI App
• Power Supply: “12V DC ± 5%, Max. 11.76 W, 5.5mm Coaxial Power Plug
  PoE: 802.3af/at, class 0, Max. 12.14W”
• Additional Features: “Multiple Display Modes and ePTZ
  Ceiling Mount; Wall Mount; Pendant Mount
  IK10 Vandal Proof
  Material: Metal

  See Overview for more features”

• Weight/Dimensions: 0.44 Kg ( without Mounting Accessories)
  0.48 Kg ( with Mounting Accessories)
  132 x 132 x 56 mm
• Environment: IP67 Weatherproof
  Operating Temperature: -30–60 °C
  Storage Temperature: -40–60 °C
  Storage Humidity: 95% or Less (Non-Condensing)
  Operating Humidity: 95% or Less (Non-Condensing)
• Package Contents: VIGI Network Camera
  Quick Start Guide
  Waterproof Cable Attachments
  Mounting Accessories
• Package Weight: 1.4600 kg
• Warranty: 5 Years
• #Hide#Resolution: 5MP
