TP-LINK (TL-WA3001) AX3000 Dual Band Gigabit Wi-Fi 6 Access Point, Passive PoE, Range Extender, Multi-SSID & Client Modes

Description

Description

Specification

• Primary Function: Access Point
• #Hide#Access Point Mode: Yes (Access Point Mode)
• #Hide#Wireless Standard: 802.11ax (Wi-Fi 6/6E)
• Bands: Dual Band
• Wi-Fi Rating: AX3000
• Max Single Band Wi-Fi Rate: 2402 Mbps
• Max Wired Transfer Rate: 10/100/1000 Mbps
• Interface(s): 1 x Gigabit Port (Supports Passive PoE)
• Wireless Standards: “IEEE802.11b/g/n/ax 2.4 GHz, IEEE 802.11a/n/ac/ax 5 GHz”
• Antenna(s): 4 x Fixed High Performance Antennas
  Beamforming Technology
• Button(s): “Power On/Off Button, WPS Button, Reset Button”
• Power Supply: External Power Supply: 48V/0.5A
• Dimensions: (WxDxH) 240 x 165 x 43.6mm
• Weatherproof: No
• Frequency: 5GHz: Up to 2402 Mbps
  2.4GHz: Up to 574 Mbps
• Reception Sensitivity: 5GHz:
  11ax HE20 MCS0:-97dBm
  11ac VHT20 MCS9:-73dBm
  11ax HE20 MCS11:-67dBm
  11ax HE40 MCS0:-94dBm
  11ac VHT40 MCS9:-70dBm
  11ax HE40 MCS11:-63dBm
  11ax HE80 MCS0:-91dBm
  11ac VHT80 MCS9:-66dBm
  11ax HE80 MCS11:-60dBm
  11ac VHT160 MCS9:-63dBm
  11ax HE160 MCS11:-58dBm
• .: 2.4GHz:
  11ac VHT20 MCS0:-97dBm
  11ac VHT20 MCS8:-73dBm
  11ax HE20 MCS11:-65dBm
  11ac VHT40 MCS0:-93dBm
  11ac VHT40 MCS9:-69dBm
  11ax HE40 MCS11:-62dBm
• Wireless Modes: “Access Point, Range Extender, Client, Multi-SSID”
• Wireless Functions: “Enable/Disable Wireless Radio, WMM, Wireless Statistics, Access Control”
• Security: “WPA, WPA2, WPA3, WPA/WPA2-Enterprise encryptions”
• DHCP: “Server, DHCP Client List”
• Quality of Service: WMM
• Additional Features: “System Tools: SNMP, Ping Watchdog
  Protocols: IPv4, IPv6

  See Overview for more features

  “

• Environment: Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F)
  Operating Humidity: 10%~90% non-condensing
• Package Contents: Wireless Access Point TL-WA3001
  Power Adapter
  RJ45 Ethernet Cable
  Quick Installation Guide
  PoE Power Injector
• Package Type: Retail
• Package Weight: 1.1800 kg
• Warranty: 3 Years
